ARM Rockchip RK3288 处理器

General
CPU	ARM Rockchip^® RK3288, Quad-Core Cortex-A17 up to 1.8GHz
Chipset	Null
Memory	1/2/4GB DDR3 1333MHz on board
Storage	1EMMC 8/16/32G, 1TF Card
Expansion Interface	1*Mini-PCIe (3G Supported)
BIOS	Null
System	Android 4.4/5.1/7.1
I/O Interface
Serial Port	6*RS232 (COM1 RS485 optional)
USB	6*USB 2.0
Ethernet	1Realtek^® PHY LAN for 1000Mbps 1Realtek^® WIFI (IEEE 802.11 b/g/n, 2.4GHz) 1*BT (FHSS BT3.0/4.0)
Audio	Everest^® CODEC ES8316, supports MIC/Line-out 1*Amplifier
PS/2	Null
Parallel Port	Null
GPIO	8 programmable GPIO
Feature Interface	2Touch Panel Header (only with USB signal) 1Infrared Pin Header
Display
Display Interface	1HDMI: max resolution up to 40962160@60Hz 1eDP: max resolution up to 40962160@30Hz 1LVDS/eDP: LVDS, Dual Channel 24 bit, max resolution up to 19201080@60Hz eDP, max resolution up to 4096*2160@30Hz
Multiple Display	Dual
Mechanical & Environment
Dimension	3.5”, 146*105mm
Power Input	DC 12V
Temperature	Operation: -20℃~60℃, Storage: -25℃~75℃
Relative Humidity	Operation: 10%~90%, Storage: 5%~95%, non-condensing
