Display Pane
|
Brand
|
MEKT明亿科
|
|
Model
|
T190VX
|
|
Size/Proportion
|
19 inch 5:4
|
|
Resolution
|
1280*1024
|
|
Brightness
|
350cd/㎡(Can be customized 1000cd/㎡)
|
|
Contrast
|
800:1
|
|
Display color
|
16.7M
|
|
Response time
|
2-5ms
|
|
Visible angle
|
85/85/80/80(Typ.CR≥10)
|
|
Pixel pitch(mm)
|
0.294(H)X 0.294(V)
|
|
Draw quality
|
3D noise reduction, high-definition signal, progressive scan
|
|
|
Touch Function
|
Touch screen
|
5-wire Resistive touch
|
|
Surface hardness
|
≥3h
|
|
Transmittance
|
>95%
|
|
Positioning accuracy
|
less than 2mm
|
|
Click lifetime
|
> 60 million times
|
|
Touch medium
|
Resistance touch pen, finger
|
|
Right-click function
|
Click on a certain point and press for more than 3 seconds
|
|
Touch interface
|
USB (optional COM)
|
|
Support system
|
win7, win8, win10, android, linux and so on
|
|
|
Motherboard
Function
|
Refresh frequency
|
60Hz
|
|
Power input
|
DC12V-36V
|
|
Functional interface
|
HD,DP,VGA,Audio
|
|
|
Work Environment
|
Operating
Temperature/humidity
|
-10℃ to +60℃/ 0-80% relative humidity, no condensation
|
|
Storage
Temperature/humidity
|
-15℃ to +65℃/ 0-90% relative humidity, no condensation
|
Product Service
|
After service
|
one-year warranty and lifelong maintenance
|
|
Customized service
|
OEM/ODM is available for material, appearance, dimensions,
wide temperature, outdoor highlight, wide voltage, etc.
|
