Display Pane

Brand

HAOFCC

Model

H185XPC

Size/Proportion

18.5 inch 16:9

discrimination rate

1366*768(Can be customized 1920*1080）

Brightness

300cd/㎡(Can be customized 1000cd/㎡)

Contrast

800:1

Display color

16.7m

Response time

2-5ms

Visible angle

85/85/85/85(Typ.CR≥10)

Pixel pitch(mm)

0.3000（H）X0.3000（V）

Draw quality

3D noise reduction, high-definition signal, progressive scan

Touch Function

Touch screen

Capacitive touch screen (10 points)

Surface hardness

≥6h

Transmittance

＞95%

Positioning accuracy

less than 2mm

Click lifetime

> 60 million times

Touch medium

Current sensing, capacitive touch pen, finger

Right-click function

click on a certain point and press for more than 3 seconds

Touch interface

USB

Support system

win7, win8, win10, android, linux and so on

Motherboard

Function

Mainboard

HAOFCC industrial motherboard

CPU

Intel Celeron 3855U dual-core dual-thread

the cpu frequency is 1.6ghz

Secondary cache 2MB

integrated graphics

intel HD Graphics 510

RAM

4GB (optional 8G)

SSD

64GB (optional 32G\128G\500G\1T)

LAN

LAN*2 100/1000M adaptive

USB

USB3.0*4,USB2.0*2

COM

COM*6

HD

HD*1

Wireless Network

Wireless card

Wifi is not available as standard (optional)

Open Close

Power

Power*1 (power-on and power-on function can be set)

Power Input

AC/DC

DC12V

Watchdog

Watch dog timer

0-255 seconds, providing watchdog routine

Product Power

Power

≤20W

Work Environment

Operating

Temperature/humidity

-10℃ to +60℃/ 0-80% relative humidity, no condensation

storage

Temperature/humidity

-15℃ to +65℃/0-90% relative humidity, no condensation

Product Service

After service

one-year warranty and lifelong maintenance

Customized service

OEM/ODM is available for material, appearance, dimensions,

wide temperature, outdoor highlight, wide voltage, etc.
