Display Pane
|
Brand
|
MEKT明亿科
|
|
Size/Proportion
|
13.3 inch 16:9
|
|
Model
|
P133WXDR
|
|
Brightness
|
450cd/㎡ 1000cd/㎡
|
|
Resolution
|
1920*1080
|
|
Contrast
|
1000:1
|
|
Display color
|
16.7M
|
|
Response time
|
2-5ms
|
|
Visible angle
|
85/85/85/85
|
|
Pixel pitch(mm)
|
0.153(H)X 0.153(V)mm
|
|
|
Touch screen
|
Touch screen
|
Projected multi-point capacitive touch screen (10 points)
|
|
Touch screen hardness
|
6H
|
|
Positioning accuracy
|
less than 2MM
|
|
Ct.Life
|
≥50 million times
|
|
Touch media
|
Capacitive Touch Pen, Fingers
|
|
Right click functionality
|
click on a point, long and hold more than 3 seconds
|
|
Touch interface
|
USB(optional COM)
|
|
Support system
|
win7, win8, win10, android, linux and so on
|
|
|
Motherboard
Function
|
Refresh frequency
|
60Hz
|
|
Power input
|
DC12-36V
|
|
Functional interface
|
HD/DP/VGA/Audio
|
|
|
Environment
|
Operating
temperature/humidity
|
-10℃ to +60℃/0-80% relative humidity, no condensation
|
|
Storage
temperature/humidity
|
-15℃ to +65℃/0-90% relative humidity, no condensation
|
|
Vibration resistant
|
30Hz, X, Y, Z axis 60 minutes each
|
|
Esd protection
|
Class 3, contact discharge ± 6KV, air discharge ±8KV
|
|
Panel level
|
IK6
|
|
Test standards
|
IEC60601
|
Product Service
|
After service
|
one-year warranty and lifelong maintenance
|
|
Customized service
|
OEM/ODM is available for material, appearance, dimensions,
wide temperature, outdoor highlight, wide voltage, etc.
|
