Brand
|
HAOFCC
|
Model
|
SD-T090WXP
|
Dimensions
|
9 "
|
Pixel
|
1920 × RGB × 1200
|
Dot Pitch
|
0.09975 (H) × 0.09975 (V) mm
|
Display ratio
|
16: 9/4: 3 convertible
|
Backlight
|
White LED
|
Brightness
|
500cd / m2
|
Contrast ratio
|
800: 1
|
Color depth
|
8Bit
|
Image processing
|
10Bit
|
Response time
|
10ms
|
Viewing angle
|
left and right 170 ° / up and down 170 °
|
3G / HD / SD-SDI
|
1x BNC
|
Composite Video (CVBS)
|
1 x BNC
|
Component
|
3 x BNC
|
HDMI
|
1 x HDMI
|
DVI
|
1 x DVI
|
VGA
|
1 x VGA
|
3G / HD / SD-SDI
|
1 x BNC
|
Composite Video (CVBS)
|
1 x BNC
|
VGA (VGA) audio input
|
support
|
Composite video (CVBS) audio input
|
support
|
Built-in speaker
|
2x 8ohm / 1W (front)
|
Audio power amplifier output
|
support
|
CVBS
|
NTSC、PAL
|
3G-SDI
|
1080p(50/60)
|
HD-SDI
|
1080i(60/59.94/50) 1080p(30/29.97/25/24/24sF/23.98/23.98sF)720p(60/59.94/50/30/29/25/24/23.98)
|
SD-SDI
|
480/59.94i、576/50i
|
Component
|
480p / 60, 480i / 60, 576i / 50, 576p / 50,720p (50/60), 1080i (/ 50/60), 1080p (24/25/30/50/60)
|
HDMI
|
480p / 60, 480i / 60, 576i / 50, 576p / 50, 720p (50/60), 1080i (/ 50/60), 1080p (24/25/30/50/60)
|
Input voltage
|
12V DC standard 2-core card aviation head
|
Power Consumption (MAX)
|
15W
|
Working temperature
|
0-40 degrees Celsius
|
Storage temperature
|
-20-70 degrees Celsius
|
Storage humidity
|
0% -90% non-condensing
|
Housing material
|
aluminum profile
|
Appearance
|
suitcase (with design)
|
Weight
|
about 4kg
|
(customized product material, appearance, wide temperature screen, high resolution, wide voltage, etc., OEM/ODM)
|
