High brightness LCD display 10.4 inches

Outdoor highlight display (TH104VXC)

Product model: TH104VXC
Resolution: 1024*768
Product brightness :1000cd/㎡
Operating temperature: -20 ~ +70℃
Storage temperature: -20 ~ +70℃
Product features:
Strong metal housing, dust - proof, anti - vibration, anti - interference
Power on startup function, OSD film button control
Support 100*100mm 75*75mm wall/desktop, embedded installation
Industrial high brightness display screen, long life
Industrial design super heat dissipation, 24 hours repetitive operation
(customized product material, appearance, wide temperature screen, high resolution, wide voltage, etc., OEM/ODM)

Details
Parameter
Consulting
Technical Data

Brand	MEKT明亿科
Model	TH104VXC
Size	10.4inch
Product ratio	4:3
Resolution	1024*768
Brightness	1000cd/㎡
Contrast	800:1
Display color	16.7M
Response time	8ms
Viewing angle	65/65/60/65 (Typ.)(CR≥10)
Pitch （mm）	0.264(H)X0.264(V)
scanning frequency	60Hz
Quality	3D noise reduction high definition signal progressive scan
The surface hardness	≥7H
Light transmittance	＞95%
Click life span	＞70 million times
power input	DC12V
Functional interface	HDMI/DVI/VGA
Panel level	IP65
Visual area	214mm*161mm
Dimensions	285mm200mm43.05mm
Working temperature	-20 ~ +70℃
Storage temperature	-20 ~ +70℃
Relative humidity	5% ~ 95% No frost
Impact	10G(11MS)
Vibration	50 ~ 500 hz, 1.5 G, 0.15 mm
The machine color	Black
Product net weight	About 3 KG
	Metal material strong chassis, dust-proof, shockproof, anti-interference
	Power on function, OSD film button control
	Support 75*75mm wall-mounted/desktop type, embedded installation
	Adopt industrial grade high brightness screen, life is longer.
	Industrial design super heat, 24 hours repeated non-stop operation
	Using the world's leading projection multi-point capacitive touch screen stable performance, positioning without drift,sensitive with touch.
The standard interface	HDMI/DVA/VGA/DC/USB(Touch the interface)
Free accessories	Power (12V2.6A)， power cord, VGA cable，manual
After-sales service	One year warranty，lifetime maintenance
Personality customization	Customizable product material, appearance, wide temperature screen, high brightness screen, high resolution, wide voltage, etc., can be OEM/ODM.
