Brand
|
MEKT明亿科
|
Model
|
TH170VXC
|
Size
|
17inch
|
Product ratio
|
4:3
|
Resolution
|
1280*1024
|
Brightness
|
1000cd/㎡
|
Contrast
|
1000:1
|
Display color
|
16.7M
|
Response time
|
8ms
|
Viewing angle
|
70/70/65/70(Typ.)(CR≥10)
|
Pitch (mm)
|
0.289(H)X0.289(V)
|
scanning frequency
|
60Hz
|
Quality
|
3D noise reduction high definition signal progressive scan
|
The surface hardness
|
≥7H
|
Light transmittance
|
>95%
|
Click life span
|
>70 million times
|
power input
|
DC12V
|
Functional interface
|
HDMI/DVI/VGA
|
Panel level
|
IP65
|
Visual area
|
339mm*272mm
|
Dimensions
|
400mm*321mm*46.28mm
|
Working temperature
|
-20 ~ +70℃
|
Storage temperature
|
-20 ~ +70℃
|
Relative humidity
|
5% ~ 95% No frost
|
Impact
|
10G(11MS)
|
Vibration
|
50 ~ 500 hz, 1.5 G, 0.15 mm
|
The machine color
|
Black
|
Product net weight
|
About 5 KG
|
|
Metal material strong chassis, dust-proof, shockproof, anti-interference
|
|
Power on function, OSD film button control
|
|
Support 100*100mm wall-mounted/desktop type, embedded installation
|
|
Adopt industrial grade high brightness screen, life is longer.
|
|
Industrial design super heat, 24 hours repeated non-stop operation
|
|
Using the world's leading projection multi-point capacitive touch screen stable performance, positioning without drift,sensitive with touch.
|
The standard interface
|
HDMI/DVA/VGA/DC/USB(Touch the interface)
|
Free accessories
|
Power (12V2.6A), power cord, VGA cable,manual
|
After-sales service
|
One year warranty,lifetime maintenance
|
Personality customization
|
Customizable product material, appearance, wide temperature screen, high brightness screen, high resolution, wide voltage, etc., can be OEM/ODM.
|
