Brand

MEKT明亿科

Model

AP104VX-3288

Size / Proportion

10.4 inches 4: 3

Resolution

1024 * 768

Brightness

350cd / ㎡

Contrast

800: 1

Display color

16.7M

Response time

2-5ms

Viewing angle

80/80/80/80 (Typ.CR≥10)

Dot pitch mm

0.264（H）X0.264（V）

Picture quality

3D Noise Reduction High Definition Signal Progressive Scan

touch screen

G + G projected capacitive multi-touch screen (10 points)

Surface hardness

≥6H

Transmittance

＞ 95%

positioning accuracy

Less than 2MM

Click life

＞ 70 million times

Touch media

Capacitive touch pen, finger (current sensing)

Right-click function

Click on a point and press and hold for more than 3 seconds

Touch interface

USB

support system

Win7、win8、win10、Android、linux Wait

Motherboard

HAOFCC  Industrial motherboard

CPU

RK3288 Cortex-A17 Architecture Quad-core clocked at 1.8GHz

RAM

2GB DDR3

Memory storage

EMMC FLASH 16G

Memory speakers

Memory speaker

Decoding resolution

Support up to 3840 * 2160

Play mode

Support multiple playback modes such as loop, timing, and insert

Network support

Ethernet LAN, wifi (expandable 3G wireless module, Bluetooth 4.0)

Video playback

Support wmv, avi, flv, rm, RMVB, MPEG, ts, TP, MKV, MOV, DAT, VOB, PMP, mp4, MPG, ASF, 3GP Wait 30 formats

Image Format

Support BMP, JPG, PNG, GIF and other picture formats to browse and support rotation / slideshow playback, up to 4096 * 4096 resolution

RTC real-time clock

stand by

Timer switch

stand by

System Upgrade

Support USB / TF card / network upgrade

operating system

Android 6.0

interface

USB2.0 * 2

RS232*1（Selectable TTL signal）

SD / TF card slot * 1

LAN * 1 10M / 100M adaptive Ethernet

Built-in wifi

HDMI * 1 supports 1080P output

Audio * 1 supports CVBS video input and output, left and right channel output

DC12V power supply

power

≤20W

Working temperature / humidity

-10 ℃ to + 55 ℃ / 0-80% relative humidity, non-condensing

Storage temperature / humidity

-10 ℃ to + 60 ℃ / 0-90% relative humidity, non-condensing

Application area

Military equipment, aerospace equipment, rail transit / communications, professional photography display, smart supermarket, smart robot, smart conference room, factory assembly line \ POS cash register, car GPS, elevator entrance, commercial office building, exhibition site, etc. occasion

Cleaning method

Spray the surface of the soft mirror cloth with screen cleaner or water to wipe the screen. Do not use alcohol, strong acid, strong alkali to wipe the screen. The case can be wiped with a soft towel or mirror cloth.

After sales service

One year warranty and lifetime maintenance

Related Certification

CE/ROHS/FCC

Custom services

Material, appearance, size, wide temperature, outdoor highlight, wide voltage, etc., can be OEM / ODM
