Outdoor touch screen display 6.4 inch high brightness LCD monitor / Shenzhen Mingyike Electronics Co., Ltd.

Custom application | Customized service | WeChat Subscription
中文版 | Reg | Login

MEKT Mingyike Industrial Control Computer Full Range Solution Provider

HOME PRODUCTS Medical Lcd Color display

Share To:

< >

High brightness touch display 6.4 inches

Resistive touch screen display (TH604V)

Brand: MEKT mingyike
Product model: TH604V
Resolution: 640*480
Product brightness :1000cd/㎡
Working temperature/humidity: -20℃ to +70℃/ 0-80% relative humidity, no condensation
Storage temperature/humidity: -20℃ to +70℃/ 0-90% relative humidity, no condensation
Product features: metal material strong - solid housing, dust - proof, anti - vibration, anti - interference
Power on startup function, OSD film button control
VESA hole spacing 75*75mm/ desktop/hanging wall and other installation methods
Industrial grade A+ display screen, longer life
Industrial design super heat dissipation, 24 hours repetitive operation
Imported resistance 5 - wire touch screen, stable performance, accurate positioning without drift, sensitive touch

Details
Parameter
Consulting
Technical Data

Brand	MEKT
Model	TH640V TH604VX
Size	6.4inch
Product ratio	4:3
Resolution	640480 1024768
Brightness	1000cd/㎡
Contrast	800:1
Display color	16.7M
Response time	2-5ms
Viewing angle	80/80/70/70(Typ.CR≥10) 60/60/50/60(Typ.CR≥10)
Pitch （mm）	0.264(H)X0.264(V)
scanning frequency	60Hz
Quality	3D noise reduction high definition signal progressive scan
Touch screen	5 line Resistance touch screen
The surface hardness	≥3H
Light transmittance	＞95%
Positioning accuracy	less than 2MM
Click life span	＞60 million times
Touch medium	resistive touch pen, finger
Right-click function	click a point, press and hold for more than 3 seconds
Support system	Win7, win8, win10, Android, linux, etc.
power input	DC12V(Customizable wide voltage 9-36V)
Functional interface	HDMI/DVI/VGA/USB
Panel level	IP65
Visual area	134mm*100mm
Dimensions	209mm140mm43mm
Working temperature	-20℃至+70℃/ 0-80% Relative humidity, non-condensing
Storage temperature	-20℃至+70℃/ 0-90% Relative humidity, non-condensing
Impact	10G(11MS)
Vibration	50 ~ 500 hz, 1.5 G, 0.15 mm
The machine color	Black（Customizable other colors）
Product net weight	About 2KG
	Metal material strong chassis, dust-proof, shockproof, anti-interference
	Power on function, OSD film button control
	Support embedded installation
	Adopt industrial grade high brightness screen, life is longer.
	Industrial design super heat, 24 hours repeated non-stop operation
	Adopt the world leading projection multi-point capacitive touch screen with stable performance, precise positioning and no drift, sensitive to touch.
Cleaning method	Spray the surface of the soft mirror cloth with screen cleaning solution or water to wipe the screen. Do not use alcohol, strong acid, strong alkali to wipe the screen. The case can be wiped with a soft towel or mirror cloth.
The standard interface	HDMI/DVA/VGA/DC/USB(Touch the interface)
Free accessories	Power (12V2.6A)， power cord, VGA cable，USB cable，manual
After-sales service	One year warranty，lifetime maintenance
Personality customization	Customizable product material, appearance, wide temperature screen, high brightness screen, high resolution, wide voltage, etc., can be OEM/ODM.
