Display Pane
|
Brand
|
HAOFCC
|
|
Model
|
HF-21-070CC 3855U
|
|
Size/Proportion
|
7 inches 16:9
|
|
Resolution
|
1024*600
|
|
Brightness
|
300cd/㎡
|
|
Contrast
|
800:1
|
|
Display color
|
16.7m
|
|
Response time
|
2-5ms
|
|
Visible angle
|
IPS
|
|
Point distance(mm)
|
0.276(h)x0.276(v)
|
|
Draw quality
|
Progressive scan of 3d noise reduction and high definition signal
|
|
|
Touch Function
|
Touch screen
|
Capacitive touch screen (10 points)
|
|
Surface hardness
|
≥6h
|
|
Transmittance
|
>90%
|
|
Positioning accuracy
|
less than 2mm
|
|
Click lifetime
|
> 60 million times
|
|
Touch medium
|
Touch pen and finger special for current sensing and capacitance
|
|
Right-click function
|
Click on a certain point and press for more than 3 seconds
|
|
Touch interface
|
USB
|
|
Support system
|
win7, win8, win10, android, linux and so on
|
|
|
Motherboard Function
|
Mainboard
|
HAOFCC industrial motherboard
|
|
CPU
|
Intel celeron 3855u dual core dual thread
|
|
|
the cpu frequency is 1.6ghz
|
|
|
Secondary cache 2MB
|
|
integrated graphics
|
intel HD Graphics 510
|
|
Graphics card frequency
|
300MHz
|
|
dynamic frequency
|
900MHz
|
|
RAM
|
4GB
|
|
SSD
|
64GB (optional 32G\128G\500G\1T)
|
|
LAN
|
LAN*2 100/1000M adaptive
|
|
USB
|
USB3.0*4
|
|
COM
|
RS232*4
|
|
HD
|
HD*2
|
|
|
Wireless Network
|
Wireless card
|
Wifi is not available as standard (optional)
|
Open Close
|
Power
|
Power*1 (power-on and power-on function can be set)
|
Power Input
|
AC/DC
|
DC12-24V
|
Watchdog
|
Watch dog timer
|
0-255 seconds, providing watchdog routine
|
Product Power
|
Power
|
≤20W
|
Work Environment
|
Operating
Temperature/humidity
|
-10℃ to +60℃/ 0-80% relative humidity, no condensation
|
|
Storage
Temperature/humidity
|
-15℃ to +65℃/ 0-90% relative humidity, no condensation
|
Product Service
|
After service
|
one-year warranty and lifelong maintenance
|
|
Customized service
|
OEM/ODM is available for material, appearance, dimensions,
wide temperature, outdoor highlight, wide voltage, etc.
|
