Display Pane
|
Brand
|
HAOFCC
|
|
Model
|
L804CC Ver.2
|
|
Size/Proportion
|
8.4 inch 4:3
|
|
Resolution
|
800*600 / 1024*768
|
|
Brightness
|
450cd/㎡(Can be customized 1000cd/㎡)
|
|
Contrast
|
800:1
|
|
Display color
|
16.7m
|
|
Response time
|
3-5ms
|
|
Visible angle
|
85/85/85/85(Typ.CR≥10)
|
|
Pixel pitch(mm)
|
0.1665×0.1665 mm [152PPI]
|
|
Draw quality
|
3D noise reduction, high-definition signal, progressive scan
|
|
|
Touch Function
|
Touch screen
|
capacitive touch screen (10 points)
|
|
Surface hardness
|
≥6h
|
|
Transmittance
|
>95%
|
|
Positioning accuracy
|
less than 2mm
|
|
Click lifetime
|
> 60 million times
|
|
Touch method
|
Current sensing, capacitive touch pen, finger
|
|
Right-click function
|
Click on a certain point and press for more than 3 seconds
|
|
Touch interface
|
usb
|
|
|
Motherboard
Function
|
Mainboard
|
HAOFCC industrial motherboard
|
|
CPU
|
Intel Celeron J6412 Quad-core
|
|
|
the cpu frequency is 2.0ghz,Max Speed Up to 2.6GHz
|
|
|
Secondary cache 1.5 MB L2 Cache
|
|
integrated graphics
|
Intel® UHD Graphics for 10th Gen Intel® Processors
|
|
graphics card frequency
|
400MHz
|
|
dynamic frequency
|
800MHz
|
|
System
|
Windows 10 IoT Enterprise(Support Windows11,Linux,UOS)
|
|
RAM
|
4G (optional 8G/16G/32G)
|
|
SSD
|
128G (optional 256G/512G/1T/2T)
|
|
LAN
|
LAN*2 Intel® 10M/100M/1000M/2.5Gbps adaptive
|
|
USB
|
USB3.0*4
|
|
COM
|
RS232(485)*4 (Customizable RS422)
|
|
HD
|
HD*1Resolution up to 4096x2160@24Hz
|
|
GPIO
|
GPIO
|
|
SIM
|
SIM*1 Micro SIM Card Slot
|
|
|
Wireless Network
|
Wireless card
|
Wifi is not available as standard (optional)
|
Open Close
|
Power
|
Power*1 (power-on and power-on function can be set)
|
Power Input
|
AC/DC
|
DC9-36V
|
Watchdog
|
Watch dog timer
|
0-255 seconds, providing watchdog routine
|
Product Power
|
Power
|
≤20W
|
Work
Environment
|
Operating
Temperature/humidity
|
-20℃ to +70℃ 0-80% relative humidity, no condensation
|
|
storage
Temperature/humidity
|
-40℃ to +80℃ 0-90% relative humidity, no condensation
|
Product Service
|
After service
|
one-year warranty and lifelong maintenance
|
|
Customized service
|
OEM/ODM is available for material, appearance, dimensions,
wide temperature, outdoor highlight, wide voltage, etc.
|
